Removable Anti Static Label Material 1Mil Gloss White Polyimide Materials With Glassine
| Place of Origin | China |
|---|---|
| Brand Name | PANLARN |
| Certification | SGS |
| Model Number | PL8520-2L-K26 |
| Minimum Order Quantity | 200 square meter |
| Price | $10~12 per square meter |
| Packaging Details | Roll |
| Delivery Time | 7-15days |
| Payment Terms | T/T,Paypal,west union,Alipay |
| Supply Ability | 10000 square meter/1 week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Polyimide | Adhesive Type | Removable Adhesive |
|---|---|---|---|
| Finish | Gloss | Colour | White |
| Film Type | Polyimide Film | Liner | Glassine |
| Highlight | Anti Static Label Material 75um,Anti Static Label Material 25um,1mil thermal transfer material |
||
Product Description
1Mil Gloss White Removable Adhesive Polyimide Materials With Glasin
Product Description:
PL8520-2L is a substrate for a polyimide, with a permanent acrylic pressure-sensitive adhesive, suitable for thermal transfer printing of the white-coated surface of the label, is designed for printed circuit boards or related electronic components used on the characters or Logo and barcode label design. It is in circuit boards and SMT, DIP during wave solder or reflow to ensure that all kinds of extreme harsh application environment to maintain excellence in the performance of an ideal material.
Product Feature :
| Title | Description |
|---|---|
| Adhesive | Removable Adhesive |
| Color | White |
| Shape | Roll |
| Face stock: | |
| Coating |
White matte finish 15um |
| Base material type | Polyimide PI film |
| Thickness | 25um+-2 |
| Liner: | |
| Liner type |
Glassine |
| Gram weight | 90g |
| Thickness | 75um+-5% |
| Adhesive | |
| Adehesive type |
Removable Adhesive |
| Thickness | 18um+-1% |
|
Release force |
0.5-0.7kgf |
| Rest standard | GB/T 2792 |
| Minimum application temperature |
5-10℃ |
| Service temperature range | -40℃~300℃ |
Applications:
- PCB board processing bar code management
- Electronic chip identification
- Electronic component identification
- Photoelectronic technique
Packing and Shipping:
- By EMS,DHLFedEx,TNT,UPS or other express
- By your forwarding agent
- Domestic freight forwarders to any city in China
- PS: If you have any questions about shipping fee, pls contact with me quickly.
