1Mil Anti Static Label Material Matte White Permanent Adhesive Antiflaming Polyimide With Glassine
| Place of Origin | China |
|---|---|
| Brand Name | PANLARN |
| Certification | SGS |
| Model Number | PL8520-3W-ZR |
| Minimum Order Quantity | 200 square meter |
| Price | $10~12 per square meter |
| Packaging Details | Roll |
| Delivery Time | 10000square meter/1 week |
| Payment Terms | T/T,Paypal,west union,Alipay |
| Supply Ability | 5KK/1week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Polyimide | Adhesive Type | Permanent Adhesive |
|---|---|---|---|
| Finish | Matte | Colour | White |
| Packaging | Roll | Film Family | Polyimide Film |
| Highlight | 1mil Anti Static Label Material,polyimide Anti Static Label Material,glassine material sticker label |
||
Product Description
1Mil Matte White Permanent Adhesive Antiflaming Polyimide Materials With Glassine
Product Description:
PL8520-2W is a substrate for polyimide, with a permanent acrylic pressure-sensitive adhesive, suitable for thermal transfer printing of the matte white-coated surface of the label, is designed for printed circuits or related electronic components used on the characters or Logo and barcode label design . It is in circuits and SMT, DIP during wave soldering or reflow to ensure that all kinds of extreme harsh application environments to maintain excellence in the performance of an ideal material.
Product Feature :
| Title | Description |
|---|---|
| Adhesive | Permanent adhesive |
| Color | White |
| Shape | Roll |
| Face stock: | |
| Coating |
White matte finish 15um |
| Base material type | Polyimide PI film |
| Thickness | 25um+-2 |
| Liner: | |
| Liner type |
Glassine |
| Gram weight | 90g |
| Thickness | 75um+-5% |
| Adhesive | |
| Adehesive type |
Permanent adhesive |
| Thickness | 25um+-1% |
|
Release force |
0.7-0.9kgf |
| Rest standard | GB/T 2792 |
| Minimum application temperature |
5-10℃ |
| Service temperature range | -40℃~300℃ |
Applications:
- PCB board processing bar code management
- Electronic component identification
- Electronic chip identification
- Cable and wire label
Packing and Shipping:
- By EMS,DHLFedEx,TNT,UPS or other express
- Domestic freight forwarders to any city in China
- By your forwarding agent
- By Sheet/Roll
