Strong Adhesive Polyimide Materials Matte White 1Mil With Glassine

Place of Origin China
Brand Name PANLARN
Certification SGS
Model Number PL8520-2W-A26
Minimum Order Quantity 200 square meter
Price $10~12 per square meter
Packaging Details Roll
Delivery Time 7-15days
Payment Terms T/T,Paypal,west union,Alipay
Supply Ability 10000 square meter/1 week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Polyimide Adhesive Type Permanent Adhesive
Finish Matte Colour White
Packaging Roll Film Polyimide Film
Highlight

1mil high temperature label materials

,

glassine high temperature label materials

,

glassine food label material

Leave a Message
Product Description

1Mil Matte White Strong Adhesive Polyimide  Materials With Glassine

Product Description:



PL8520-2W is a polyimide-based label with a permanent pressure sensitive acrylic adhesive, white-colored matte coated surface for thermal transfer, designed for use in printed circuit boards or connected electronic components for character tags or logo and bar code. It is the ideal material for welding waves or refilling welding during circuit boards and SMTs, DIP to ensure excellent performance in a wide range of extremely harsh application environments.







Product Feature :

Title Description
Adhesive Strong adhesive
Color White
Shape Roll
Face stock:
Coating

White matte finish 15um

Base material type Polyimide PI film
Base material thickness 25um+-2
Liner:
Liner type

Glassine

Gram weight 90g
Thickness 75um+-5%
Adhesive
Adehesive type

Permanent  adhesive

Thickness 25um+-1%

Release force

0.9-1.1kgf
Rest standard GB/T 2792
Minimum application temperature

5-10

Service temperature range -40℃~300









    Strong Adhesive Polyimide Materials Matte White 1Mil With Glassine 0











Applications:



  • PCB board processing bar code management
  • Electronic component identification
  • Electronic chip identification
  • Component tracking bar codes
  •

Packing and Shipping:

  • By EMS,DHLFedEx,TNT,UPS or other express
  • Domestic freight forwarders to any city in China
  • By your forwarding agent
  • By Sheet/Roll

Strong Adhesive Polyimide Materials Matte White 1Mil With Glassine 1
