Matte Black Anti Static Label Material Permanent Adhesive Polyimide 1Mil With Glassine

Place of Origin China
Brand Name PANLARN
Certification SGS
Model Number PL8520-2W-E
Minimum Order Quantity 200 square meter
Price $10~12 per square meter
Packaging Details Roll
Delivery Time 7-15days
Payment Terms T/T,Paypal,west union,Alipay
Supply Ability 10000 square meter/1 week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Type Polyimide Adhesive Permanent Adhesive
Surface Matte Color Black
Film Polyimide Film Liner Glassine
Highlight

Anti Static Label Material glassine

,

SMT Anti Static Label Material

,

75um heat transfer label material

Leave a Message
Product Description

1Mil Gloss Black Permanent Adhesive Antistatic Polyimide Materials With Glassine

Product Description:



PL8520-2W-E is an element of polyamide that has permanent acrylic pressure-sensitive adhesion, suitable for heat transfer printing of the label's matte white-coated surface, designed for related electronic components used on printed circuit boards or letters, or logo and barcode label design. The circuit boards and SMT, during wave solder or reflow, will be in DIP to ensure all kinds of extremely hard application environment to maintain excellence in the performance of the ideal material.





Product Feature :

Title Description
Adhesive Permanent Adhesive
Color Black
Shape Roll
Face stock:
Coating

White gloss finish 15um

Base material type Polyimide PI film
Thickness 25um+-2
Liner:
Liner type

Glassine

Gram weight 90g
Thickness 75um+-5%
Adhesive
Adehesive type

Permanent Adhesive

Thickness 25um+-1%

Release force

0.7-0.9kgf
Rest standard GB/T 2792
Minimum application temperature

5-10

Service temperature range -40℃~300

Matte Black Anti Static Label Material Permanent Adhesive Polyimide 1Mil With Glassine 0





Applications:


  •

• Printed circuit board labels and shielding
• Compliance information
• Cable and wire labels
• Component tracking bar codes

Packing and Shipping:

  • By EMS,DHLFedEx,TNT,UPS or other express
  • By your forwarding agent
  • Domestic freight forwarders to any city in China

Matte Black Anti Static Label Material Permanent Adhesive Polyimide 1Mil With Glassine 1
