2Mil High Temperature Adhesive Label Material Matte White Permanent Adhesive Polyimide With Glassine
| Place of Origin | China |
|---|---|
| Brand Name | PANLARN |
| Certification | SGS |
| Model Number | PL8520-3W |
| Minimum Order Quantity | 200 square meter |
| Price | $13~15 per square meter |
| Packaging Details | Roll |
| Delivery Time | 7-15days |
| Payment Terms | T/T,Paypal,west union,Alipay |
| Supply Ability | 10000 square meter/1 week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material Type | Polyimide | Adhesive | Permanent Adhesive |
|---|---|---|---|
| Finish | Matte | Colour | White |
| Film | Polyimide Film | Liner | Glassine |
| Highlight | High Temperature Adhesive Label Material 2 mil,High Temperature Adhesive Label Material matte white,70um High Temperature Adhesive Label Material |
||
Product Description
2Mil Matte White Permanent Adhesive Polyimide Materials With Glassine
Product Description:
PL8520-3W is a substrate for polyimide, with pressure-sensitive permanent acrylic adhesive, suitable for thermal transfer printing of matte white label surface, is designed for printed circuit boards or related electronic components used on characters or logo and label barcode. It is in circuit boards and SMT, DIP during wave solder or remelting to ensure that all kinds of extremely harsh application environment maintain the excellent performance of the ideal material.
Product Feature :
| Title | Description |
|---|---|
| Adhesive | Permanent Adhesive |
| Color | White |
| Shape | Roll |
| Face stock: | |
| Coating |
White matte finish 15um |
| Base material type | Polyimide PI film |
| Thickness | 50um+-2 |
| Liner: | |
| Liner type |
Glassine |
| Gram weight | 80g |
| Thickness | 70um+-5% |
| Adhesive | |
| Adehesive type |
Permanent Adhesive |
| Thickness | 25um+-1% |
|
Release force |
0.7-0.9kgf |
| Rest standard | GB/T 2792 |
| Minimum application temperature |
5-10℃ |
| Service temperature range | -40℃~300℃ |
Applications:
- PCB board processing bar code management
- Electronic chip identification
- Electronic component identification
- Printed circuit board labels and shielding
Packing and Shipping:
- By EMS,DHLFedEx,TNT,UPS or other express
- By your forwarding agent
- Domestic freight forwarders to any city in China
