1Mil High Temperature Adhesive Label Material Matte Green Permanent Adhesive Polyimide With Glassine
| Place of Origin | China |
|---|---|
| Brand Name | PANLARN |
| Certification | SGS |
| Model Number | PL8520-2W-G |
| Minimum Order Quantity | 200 square meter |
| Price | $10~12 per square meter |
| Packaging Details | Roll |
| Delivery Time | 7-15days |
| Payment Terms | T/T,Paypal,west union,Alipay |
| Supply Ability | 10000square meter/1 week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material Type | Polyimide | Adhesive | Permanent Adhesive |
|---|---|---|---|
| Finish Type | Matte | Colour | Green |
| Shape | Roll | Film Family | Polyimide Film |
| Highlight | 1 mil High Temperature Adhesive Label Material,polyimide High Temperature Adhesive Label Material,glassine High Temperature Adhesive Label Material |
||
Product Description
1Mil Matte Green Permanent Adhesive Polyimide Materials With Glassine
Product Description:
Pl8520-2w is a substrate for polyimide and is a permanent acrylic pressure-sensitive adhesive suitable for heat transfer printing of label's flat white coating surfaces and is designed for printed circuit boards or related electronic components used in character or logo and bar code label designs. It guarantees all kinds of extreme harsh application environment to maintain excellence in performance of the ideal material in circuit board and SMT, wave solder or DIP during reflow.
Product Feature :
| Title | Description |
|---|---|
| Adhesive | Permanent adhesive |
| Color | Green |
| Shape | Roll |
| Face stock: | |
| Coating |
White matte finish 15um |
| Base material type | Polyimide PI film |
| Base material thickness | 25um+-2 |
| Liner: | |
| Liner type |
Glassine |
| Gram weight | 90g |
| Thickness | 75um+-5% |
| Adhesive | |
| Adehesive type |
Permanent adhesive |
| Thickness | 25um+-1% |
|
Release force |
0.9-1.1kgf |
| Rest standard | GB/T 2792 |
| Minimum application temperature |
5-10℃ |
| Service temperature range | -40℃~300℃ |
Applications:
- PCB board processing bar code management
- Component tracking bar code
- Electronic chip identification
- Printed circuit board label
Packing and Shipping:
- By EMS,DHLFedEx,TNT,UPS or other express
- Domestic freight forwarders to any city in China
- By your forwarding agent
