1Mil High Temperature Adhesive Label Material Matte Yellow Permanent Adhesive Polyimide With Glassine
| Place of Origin | China |
|---|---|
| Brand Name | PANLARN |
| Certification | SGS |
| Model Number | PL8520-2W-Y |
| Minimum Order Quantity | 200 square meter |
| Price | $10~12 per square meter |
| Packaging Details | Roll |
| Delivery Time | 7-15days |
| Payment Terms | T/T,Paypal,west union,Alipay |
| Supply Ability | 10000square meter/1 week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Polyimide | Adhesive Type | Permanent Adhesive |
|---|---|---|---|
| Surface | Matte | Colour | Yellow |
| Film | Polyimide Film | Liner | Glassine |
| Highlight | High Temperature Adhesive Label Material 1 mil,High Temperature Adhesive Label Material polyimide,matte yellow High Temperature Adhesive Label Material |
||
Product Description
1Mil Matte Yellow Permanent Adhesive Polyimide Materials With Glassine
Product Description:
PL8520-2W is a polyamide substrate, with a permanent adhesive that is acrylic pressure-sensitive, suitable for thermal printing of the painted white surface of the label, and designed for printed circuit boards or related electronic components used in the design of the affixed symbols or emblem and code. They are present in circuit boards, SMT and DIP during wavewelding or reflow to ensure that all types of application environment are too harsh to maintain excellence in optimal material performance.
Product Feature :
| Title | Description |
|---|---|
| Adhesive | Permanent Adhesive |
| Color | Yellow |
| Shape | Roll |
| Face stock: | |
| Coating |
Yellow matte finish 15um |
| Base material type | Polyimide PI film |
| Thickness | 25um+-2 |
| Liner: | |
| Liner type |
Glassine |
| Gram weight | 90g |
| Thickness | 75um+-5% |
| Adhesive | |
| Adehesive type |
Permanent Adhesive |
| Thickness | 25um+-1% |
|
Release force |
0.7-0.9kgf |
| Rest standard | GB/T 2792 |
| Minimum application temperature |
5-10℃ |
| Service temperature range | -40℃~300℃ |
Applications:
- Printed circuit board labels and shielding
- Compliance information
- Cable and wire labels
- Component tracking bar code
- Electronic chip identification
Packing and Shipping:
- By EMS,DHLFedEx,TNT,UPS or other express
- By land,sea,air
- Domestic freight forwarders to any city in China
