1Mil High Temperature Adhesive Label Material Matte Red Permanent Adhesive Polyimide With Glassine
| Place of Origin | China |
|---|---|
| Brand Name | PANLARN |
| Certification | SGS |
| Model Number | PL8520-2W-M |
| Minimum Order Quantity | 200 square meter |
| Price | $10~12 per square meter |
| Packaging Details | Roll |
| Delivery Time | 7-15days |
| Payment Terms | T/T,Paypal,west union,Alipay |
| Supply Ability | 10000 square meter/1 week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material Type | Polyimide | Adhesive | Permanent Adhesive |
|---|---|---|---|
| Surface | Matte | Colour | Red |
| Shape | Roll | Film | Polyimide Film |
| Highlight | 1mil High Temperature Adhesive Label Material,matte red High Temperature Adhesive Label Material,25um High Temperature Adhesive Label Material |
||
Product Description
1Mil Matte Red Permanent Adhesive Polyimide Materials With Glassine
Product Description:
PL8520-2W is a polyimide substrate with pressure-sensitive permanent acrylic adhesive suitable for thermal transfer printing of matte white coated label surfaces for printed circuit boards or related electronic components used on signs. Logo and barcode label design. It is available in DIP for circuit boards and SMT, wave soldering or reflow, and allows for maximum material performance, ideal for all types of extreme application environments.
Product Feature :
| Title | Description |
|---|---|
| Adhesive | Permanent adhesive |
| Color | Red |
| Shape | Roll |
| Face stock: | |
| Coating |
Red matte finish 15um |
| Base material type | Polyimide PI film |
| Base material thickness | 25um+-2 |
| Liner: | |
| Liner type |
Glassine |
| Gram weight | 90g |
| Thickness | 75um+-5% |
| Adhesive | |
| Adehesive type |
Permanent adhesive |
| Thickness | 25um+-1% |
|
Release force |
0.7-0.9kgf |
| Rest standard | GB/T 2792 |
| Minimum application temperature |
5-10℃ |
| Service temperature range | -40℃~300℃ |
Applications:
- Electronic chip identification
- Component tracking bar codes
- Printed circuit board label
- Photoelectronic technique
Packing and Shipping:
- By EMS,DHLFedEx,TNT,UPS or other express
- Domestic freight forwarders to any city in China
- By Sheet/Roll
