Polyimide Materials Permanent Adhesive Matte White 1Mil With Glassine
| Place of Origin | China |
|---|---|
| Brand Name | PANLARN |
| Certification | SGS |
| Model Number | PL8520-4W |
| Minimum Order Quantity | 200 square meter |
| Price | $10~12 per square meter |
| Packaging Details | Roll |
| Delivery Time | 7-15days |
| Payment Terms | T/T,Paypal,west union,Alipay |
| Supply Ability | 10000 square meter/1 week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material Type | Polyimide | Adhesive | Permanent Adhesive |
|---|---|---|---|
| Surface | Matte | Color | White |
| Shape | Roll | Film | Polyimide Film |
| Highlight | 1mil raw material label,polyimide raw material label,matte white shrink sleeve material |
||
Product Description
1Mil Matte White Permanent Adhesive Polyimide Materials With Glassine
Product Description:
PL8520-4W is a polyimide-based label with permanent pressure-sensitive acrylic adhesive, white matte coated surface for heat transfer, designed for use on printed circuit boards or connected electronic components for branded labels or logo and barcode. Being an ideal material for welding waves or welding filling during PCBs and SMT, DIP ensures excellent performance in a wide range of very harsh application environments.
Product Feature :
| Title | Description |
|---|---|
| Adhesive | Permanent adhesive |
| Color | White |
| Shape | Roll |
| Face stock: | |
| Coating |
White matte finish 15um |
| Base material type | Polyimide PI film |
| Base material thickness | 25um+-2 |
| Liner: | |
| Liner type |
Glassine |
| Gram weight | 90g |
| Thickness | 75um+-5% |
| Adhesive | |
| Adehesive type |
Permanent adhesive |
| Thickness | 25um+-1% |
|
Release force |
0.7-0.9kgf |
| Rest standard | GB/T 2792 |
| Minimum application temperature |
5-10℃ |
| Service temperature range | -40℃~300℃ |
Applications:
- PCB board processing bar code management
- Electronic chip identification
- Component tracking bar codes
Packing and Shipping:
- By EMS,DHLFedEx,TNT,UPS or other express
- Domestic freight forwarders to any city in China
- By your forwarding agent
- By Sheet/Roll
