1Mil Anti Static Label Material Matte Buff Permanent Adhesive Polyimide Materials For PCB Label
| Place of Origin | Guangdong |
|---|---|
| Brand Name | PANLARN |
| Certification | SGS |
| Model Number | PL8520-2W-YU |
| Minimum Order Quantity | 200 square meter |
| Price | $10~12 per square meter |
| Packaging Details | Roll |
| Delivery Time | 7-15days |
| Payment Terms | T/T,Paypal,west union,Alipay |
| Supply Ability | 10000square meter/1 week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Polyimide | Adhesive Type | Permanent Adhesive |
|---|---|---|---|
| Surface | Matte | Color | Buff |
| Film Family | Polyimide Film | Liner | Glassine |
| Highlight | matte buff Anti Static Label Material,SMT Anti Static Label Material,PCB sticker label material |
||
Product Description
1Mil Matte Buff Permanent Adhesive Polyimide Materials With Glassine
Product Description:
PL8520-2W-YU is a substrate for a polyimide, with a permanent acrylic pressure-sensitive adhesive, suitable for thermal transfer printing of the buff matte coated surface of the label, is designed for printed circuit boards or related electronic components used on the characters or Logo and barcode label design. It is in circuit boards and SMT, DIP during wave solder or reflow to ensure that all kinds of extreme harsh application environment to maintain excellence in the performance of an ideal material.
Product Feature :
| Title | Description |
|---|---|
| Adhesive | Permanent Adhesive |
| Color | Buff |
| Shape | Roll |
| Face stock: | |
| Coating |
Buff matte 15um |
| Base material type | Polyimide film |
| Thickness | 25um+-2 |
| Liner: | |
| Liner type |
Glassine |
| Gram weight | 90g |
| Thickness | 75um+-5% |
| Adhesive | |
| Adehesive type |
Permanent Adhesive |
| Thickness | 25um+-1% |
|
Release force |
0.7-0.9kgf |
| Rest standard | GB/T 2792 |
| Minimum application temperature |
5-10℃ |
| Service temperature range | -40℃~300℃ |
Applications:
• Printed circuit board labels and shielding
• Compliance information
• Cable and wire labels
• Component tracking bar codes
Packing and Shipping:
- By EMS,DHLFedEx,TNT,UPS or other express
- By your forwarding agent
- Domestic freight forwarders to any city in China
